Assembly Instructions
Electroline terminations have been used with ropes since 1933. The strength of the termination, ease of assembly, and the
ability to inspect for proper termination, contribute to the continued acceptance of these fittings.
Following these simple steps is your assurance of a durable installation. However, many factors determine the safety of any rope assembly. Please observe all use and care instructions supplied with the rope.
Following these simple steps is your assurance of a durable installation. However, many factors determine the safety of any rope assembly. Please observe all use and care instructions supplied with the rope.
Recommended Tools
- Assembly Blocks: helps prevent damage to the rope*
- Plug Driver: helps seat the plug*
- Hammer
- Screwdriver
- Wrench
- Vise
* For swageless connections, included in Electroline Assembly Kits
Wire Rope Products

Electroline Assembly - General Instructions
For “M” Series Plugs: 300, 500, 700, 800, 1500, 1600, 1700, 1800, 1900, 2500, 2600, 3200

3-Strand Fittings
1400-Series Plugs for use with 3-Strand Rope

Safe-line Clamps

Latch Kits
Single- and double-latches for Electroline Hooks

Electro-Mechanical Fitting
For Double and Triple Armored Electro-Mechanical Cables
Synthetic Rope Products

SD-1000 Series Plug
SD-1000, M1400 and M1600 Series Plugs For Synthetic Rope

SDR-1000 Series Plug
SDR-1000 Series Plugs for Synthetic Rope

Lifeline and Jacketed Kevlar Fittings
MA3800A-Series Cast 2-Piece, Segmented Plug

IK Fittings
M*4000 & M*4200 Series Plugs For Braided Kevlar, Nylon and Polyester Synthetic Rope
